Description
Compatible Models
D6D/D6M/D6N/D6H/D6M/D6N/D6K/D6R//D7G/D7F/D7H/D7R/D8R/D8K/D8N/D9N/D9G/D9R/320D2/320NGH/322BL/323D/ 325C/325D/326D2/329D/330B/330C/330D/336D/336D2/345D/349D/365C/374FL/390DL/390FL/120H/120G/140H/140K/ 140G/14M3/16G/16M3/740B/773E/777D/773D/772G/740B/773B/935/938F/966C/966H/950F/950GC/980C/990H/992G
| Typical Characteristics | ||
| NLGI | 1 | 2 |
| Color | Gray Black | |
| Molybdenum Disulfide, % | 5 | 5 |
| Operating Temperature Range, ?C | -20 to +140 | -15 to +140 |
| Operating Temperature Range, ?F | -4 to +284 | +5 to +284 |
| Base Oil Type | Mineral | |
| ASTM D445 Base Oil Viscosity 40?C, mm?/s | 150 | |
| Thickener Type | Calcium Sulfonate | |
| ASTM D2265 Dropping point, ?C | > 260 | > 260 |
| ASTM D2266 4 Ball wear, scar diameter, mm | 0.39 | 0.39 |
| ASTM D2596 4 Ball weld load, kg | 800 | 800 |
| ASTM D1743 Rust prevention | Pass | Pass |
| ASTM D4048 Copper corrosion | 1A | 1A |
| ASTM D1264 Water wash-out, 79?C, mass % | 0.6 | 0.6 |
The values shown are typical values and should not be used as quality control parameters to either accept or reject product.
Specifications are subject to change without notice.
